LUX SPIKE

With its bold design, Lux Spike is designed for outdoor settings that require a high level of stability and durability. Lux Spike is an adjustable anodized aluminium spotlight, supported by a sturdy stainless steel spike. It is available in size M and offers a variety of optical beams, color temperatures, and finishes.

  • LUX SPIKE / M

    Material:

    Anodized aluminium

    Dimensions:

    M

    CCT/Colored LED:

    2700K, 3000K, 4000K / Blue, Green, Amber, Red

    CRI:

    >90

    Adjustability:

    Yes

    Wattage:

    5,8W (max 500mA) / Coloured LEDs versions: 2,1W (max700mA)

    Feeding:

    350mA / 500mA / 700mA

    Dimmable:

    Yes

    IP:

    67

    Finishes:

    AN

    Ink Black

    AA

    Silver Grey

    LUX SPIKE / M
    Max 500mA (5,8W)
    LXMGP03
    Optical lens
    03 17°
    06 46°
    CCT(K)
    D
    N
    W
    2700K
    4000K
    3000K
    Delivered flux
    435lm (500mA)
    532lm (500mA)
    484lm (500mA)
    CRI
    >90
    >90
    >90
    Bezel
    D Dark
    F Flat
    Finishes
    AA Silver Grey
    AN Ink Black
    Opt. Internal Accs.
    H Honeycomb
    O Opal filter
    Example Code: LXMGP0303DFAAH

    Note:
    Dimensions with Dark Bezel (W,D,H):ø48x101x800mm
    Dimensions with Flat Bezel (W,D,H):ø48x91x800mm
    Compatible controls: 1-10V / DALI / Triac / Casambi
    Driver not included
    Cable length 2m
    Series connection

    -20/50/max350mA
    LUX SPIKE / M (Coloured LEDs versions)
    MAx 700mA (2,1W)
    LXMGP06
    Optical lens
    03 17°
    06 46°
    Colored LEDs
    A Amber
    B Blue
    R Red
    V Green
    Bezel
    D Dark
    F Flat
    Finishes
    AA Silver Grey
    AN Ink Black
    Opt. Internal Accs.
    H Honeycomb
    O Opal filter
    Example Code: LXMGP0603BFAAH

    Note:
    Dimensions with Dark Bezel (W,D,H):ø48x101x800mm
    Dimensions with Flat Bezel (W,D,H):ø48x91x800mm
    Compatible controls: 1-10V / DALI / Triac / Casambi
    Driver not included
    Cable length 2m
    Series connection

    -20/50/max350mA
    Optional Internal Accessories

    H

    Honeycomb
    Black finish

    O

    Opal filter

    Note: Not included. To be requested when ordering / Non inclusi. Da richiedere al momento dell'ordine

    Optional External Accessories

    BLUXMSNOOT45

    Snoot 45°
    Black finish

    BLUXMSNOOT

    Black finish

    Note: Not included / Non inclusi

    AN
    Ink Black
    AA
    Silver Grey
Filters
